Turbo-Prop Engines

TURBO PROP ENGINES:

Turboprop engines are a type of aircraft powerplant that use a gas turbine to drive a propeller. The gas turbine is designed specifically for this application, with almost all of its output being used to drive the propeller. The engine's exhaust gases contain little energy compared to a jet engine and play a minor role in the propulsion of the aircraft.

In its simplest form, a turboprop consists of an intake, compressor, combustor, turbine and a propelling nozzle. Air is drawn into the intake and compressed by the compressor. Fuel is then added to the compressed air in the combustor, where the fuel-air mixture then combusts. The hot combustion gases expand through the turbine. Some of the power generated by the turbine is used to drive the compressor. The rest is transmitted through the reduction gearing to the propeller. Further expansion of the gases occurs in the propelling nozzle, where the gases exhaust to atmospheric pressure. The propelling nozzle provides a relatively small proportion of the thrust generated by a turboprop.

The world's first turboprop was the Jendrassik Cs-1, designed by the Hungarian mechanical engineer György Jendrassik. It was produced and tested in the Ganz factory in Budapest between 1939 and 1942. It was planned to fit to the Varga RMI-1 X/H twin-engined reconnaissance bomber designed by László Varga in 1940, but the program was cancelled. Jendrassik had also designed a small-scale 75 kW turboprop in 1937. However, Jendrassik's achievement was not unnoticed. After WW2, György Jendrassik moved to London. Building off a similar principle the first British turboprop engine was the Rolls Royce RB.50 Trent.

While the Soviet Union had the technology to create a jet-powered strategic bomber comparable to Boeing's B-52 Stratofortress, they instead produced the Tupolev Tu-95, powered with four Kuznetsov NK-12 turboprops, mated to eight contra-rotating propellers (two per nacelle) with supersonic tip speeds to achieve maximum cruise speeds in excess of 575 mph, faster than many of the first jet aircraft and comparable to jet cruising speeds for most missions. The Bear would serve as their most successful long-range combat and surveillance aircraft and symbol of Soviet power projection throughout the end of the 20th century. The USA would incorporate contra-rotating turboprop engines, such as the ill-fated Allison T40, into a series of experimental aircraft during the 1950s, but none would be adopted into service.

The first turbine powered, shaft driven helicopter was the Bell XH-13F, a version of the Bell 47 powered by Continental XT-51-T-3 (Turbomeca Artouste) engine

TECHNOLOGICAL ASPECTS:

In a turboprop, much of the jet thrust is sacrificed in favor of shaft power, which is obtained by extracting additional power (to that necessary to drive the compressor) from the turbine expansion process. While the power turbine may be integral with the gas generator section, many turboprops today feature a free power turbine, on a separate coaxial shaft. This enables the propeller to rotate freely, independent of compressor speed. Owing to the additional expansion in the turbine system, the residual energy in the exhaust jet is low. Consequently, the exhaust jet produces (typically) less than 10% of the total thrust.

Propellers lose efficiency as aircraft speed increases, so turboprops are normally not used on high-speed aircraft. However, propfan engines, which are very similar to turboprop engines, can cruise at flight speeds approaching Mach 0.75. To increase the efficiency of the propellers, a mechanism can be used to alter the pitch, thus adjusting the pitch to the airspeed. A variable pitch propeller, also called a controllable pitch propeller, can also be used to generate negative thrust while decelerating on the runway. Additionally, in the event of an engine outage, the pitch can be adjusted to a vaning pitch (called feathering), thus minimizing the drag of the non-functioning propeller.
